SF0845012

Name: SF0845012 - Filtronetics
SKU: SF0845012
Availability: InStock

Bandpass Filters - Filters

RoHS Compliant

Capabilities

Model Number:

SF0845012

Frequency

845 MHz

Insertion Loss

3.0 dB Max

Pass Bandwidth

839~851MHz / 0.5 dB Max

Stop Bandwidth

10~804MHz / 35 dB Min // 869~894MHz / 30 dB Min // 894~1500MHz / 35 dB Min // 1500~2000MHz / 30 dB Min // 2000~3000 MHz / 20 dB Min

Ripple

1.8 dB Max

Case

3.0 x 3.0 x 1.4mm (SMD)

Operating Temperature

-40 to +125°C

Poles

Impedance

50 Ohms

Cutoff Frequency

Frequency Range

High Center Frequency

High Pass Bandwidth

Load

Low Center Frequency

Low Pass Bandwidth

Rise/Fall Time

Size

Type of filter

Bandpass

Logic

Sort

Type
