Filtronetics has 5 decades of experience in the RF Industry. Experience that transforms your design obstacles into our solutions. We employ a technical/engineering staff with an average of 20+ years experience per person. Their range of expertise includes Electrical Engineering, Mechanical Engineering, Auto-Cad, Hi-Reliability Design & Assembly, PC Board Layout, Test & Verification and Specialized Troubleshooting.
We take pride in achieving a greater than 99% on-time delivery rate. We know how important on-time delivery is to our customers and we make it a priority.
0 products found.
Model Number
Frequency
Pass Bandwidth
Stop Bandwidth
Insertion Loss
Ripple
Case
Frequency
276.48 MHz
Pass Bandwidth
±4.0 MHz / 1.0 dB Max
Stop Bandwidth
35 MHz / 50 dB Min
Insertion Loss
5.0 dB Max in Passband
Ripple
1.0 dB Max in Pass Band
Case
38.0 x 36.5 x 7.5mm (SMD)
Frequency
310.0 MHz
Pass Bandwidth
±5.0 MHz / 3.0 dB Max
Stop Bandwidth
240 MHz / 60 dB Min // 330 MHz / 53 dB Min
Insertion Loss
3.0 dB Max at Fo
Ripple
1.0 dB Max in Pass Band
Case
38.0 x 33.5 x 7.5mm (SMD)
Frequency
310.0 MHz
Pass Bandwidth
±6.0 MHz / 3.0 dB Max
Stop Bandwidth
285 MHz / 50 dB Min // 335 MHz / 50 dB Min
Insertion Loss
3.0 dB Max at Fo
Ripple
1.0 dB Max in Pass Band
Case
38.0 x 33.5 x 7.5mm (SMD)
Frequency
325.0 MHz
Pass Bandwidth
10 MHz / 3.0 dB Max
Stop Bandwidth
DC ~ 300MHz / 37 dBc Min // 345 ~ 600MHz / dBc Min
Insertion Loss
2.0 dB Max within Fc ± 2.5 MHz
Ripple
1.0 dB Max within Fc ± 2.5 MHz
Case
32.0 x 28.5 x 7.5 mm (SMD)
Frequency
336 MHz
Pass Bandwidth
±2.5 MHz / 1.0 dB Max
Stop Bandwidth
±10 MHz / 40 dB Min
Insertion Loss
4.5 dB Max at Fo 3.0 dB Max
Ripple
1.0 dB Max in Pass Band
Case
38.0 x 29.0 x 7.5 mm (SMD)
Frequency
337.92 MHz
Pass Bandwidth
±4 MHz / 1.0 dB Max
Stop Bandwidth
35 MHz / 50 dB Min
Insertion Loss
5.0 dB Max in PB
Ripple
1.0 dB Max in PB
Case
38.0 x 32.0 x 7.5 mm (SMD)
Frequency
338 MHz
Pass Bandwidth
20 MHz / 1.0 dB Max
Stop Bandwidth
At 288 MHz / 45 dB Min // At 388 MHz / 45 dB Min
Insertion Loss
3.0 dB Max @ Fo
Ripple
1.0 dB Max in PB
Case
32 x 25 x 13.5 mm (SMD)
Frequency
350 MHz
Pass Bandwidth
5.0 MHz / 1.0 dB Max
Stop Bandwidth
250 MHz / 50 dB Min // 450 MHz / 50 dB Min
Insertion Loss
3.0 dB Max in Passband
Ripple
1.0 dB Max in Pass Band
Case
14.0 x 30.0 x 5.5mm (SMD)
Frequency
350 MHz
Pass Bandwidth
14 MHz / 3.0 dB Max
Stop Bandwidth
At 323 MHz / 33 dB Min
Insertion Loss
3.2 dB Max in PB
Ripple
1.0 dB Max
Case
17.8 x 28.2 x 5.2 mm (SMD)
Frequency
358.05 MHz
Pass Bandwidth
8 MHz / 3 dB Max
Stop Bandwidth
At Fo±10.23 MHz / 20 dB Min // At Fo±71.61 MHz / 50 dB Min // At Fo±143.22 MHz / 60 dB Min
Insertion Loss
4.0 dB Max at Fo
Ripple
Case
25.65 x 29 x 7.5 mm (SMD)
Frequency
365 MHz
Pass Bandwidth
20 MHz / 2 dB Max
Stop Bandwidth
At 305 MHz / 45 dB Min // At 425 MHz / 45 dB Min
Insertion Loss
3.0 dB Max @ Fo
Ripple
1.5 dB Max in BW
Case
27.0 x 24.5 x 7.0 mm (SMD)
Frequency
365 MHz
Pass Bandwidth
±10 MHz / 1.5 dB Max
Stop Bandwidth
At 333 MHz / 50 dBc Min // At 397 MHz / 47 dB Min
Insertion Loss
3.0 dB Max at Fo
Ripple
0.8 dB Max in PB
Case
26.0 x 28.0 x 5.5 mm (SMD)
Frequency
378 MHz
Pass Bandwidth
13.2 MHz / 1 dB Max
Stop Bandwidth
250 MHz / 60 dB Min
Insertion Loss
2.0 dB Max in Fo+/-6.6 MHz
Ripple
0.6 dB Max in Fo+/-6.6 MHz
Case
14 x 25.5 x 5.1 mm (SMD)
Frequency
380 MHz
Pass Bandwidth
±5 MHz / 3 dB Max
Stop Bandwidth
±20 MHz / 15 dB Min // ±40 MHz / 25 dB Min
Insertion Loss
2.0 dB Max at Fo
Ripple
Case
14 x 27 x 7.3 mm (SMD)
Frequency
380 MHz
Pass Bandwidth
±5 MHz / 3 dB Max
Stop Bandwidth
±20 MHz / 15 dB Min // ±40 MHz / 25 dB Min
Insertion Loss
2.0 dB Max at Fo
Ripple
Case
14 x 26.5 x 5.1 mm (SMD)
Frequency
382.5 MHz
Pass Bandwidth
±2.5 MHz / 3 dBc Max
Stop Bandwidth
At 390 MHz / 12 dBc Min
Insertion Loss
3.5 dB Max at Fo
Ripple
Case
10 x 26 x 5.1 mm (SMD)
